90° PIPE ELBOWS BUTT WELD



SIZE

SCH 10

316

SCH 40

316

SCH 10

304

SCH 40

304



12mm
18mm
25mm
31mm
38mm
50mm
63mm
76mm
100mm
125mm
150mm
200mm
250mm
300mm
4.00
5.00
6.00
9.00
11.00
16.00
22.00
28.00
48.00
95.00
120.00
320.00
POA
POA

(10E6)

4.50
5.50
7.00
12.00
14.00
19.00
36.00
48.00
88.00
175.00
265.00
790.00
POA
POA

(40E6)

-
-
5.00
8.00
9.50
13.50
19.00
24.00
41.00
81.00
102.00
225.00
POA
POA

(10E4)

-
-
6.00
10.50
12.00
16.00
31.00
41.00
75.00
148.00
204.00
560.00
POA
POA

(40E4)



CLICK HERE FOR BASIC DIMENSIONS





SHORT RADIUS 90° PIPE ELBOWS BUTT WELD



SIZE

SCH 10

316

SCH 40

316



25mm
31mm
38mm
50mm
63mm
76mm
100mm

125mm
150mm


8.00

10.00

12.00

17.00

23.00

30.00

48.00

 95.00

120.00

(10E6SR)

9.00

13.00

15.00

20.00

37.00

50.00

88.00

175.00

265.00

(40E6SR)



CLICK HERE FOR BASIC DIMENSIONS





45° PIPE ELBOWS BUTT WELD



SIZE SCH 10

316

SCH 40

316



12mm
18mm
25mm
31mm
38mm
50mm
63mm
76mm
100mm
125mm
150mm
200mm
250mm
300mm

POA
POA
5.00
7.50
9.00
13.00
18.00
23.00
39.00
76.00
96.00
256.00
POA
POA

(10E45)

POA
POA
6.00
10.00
11.50
15.50
29.00
39.00
71.00
140.00
212.00
632.00
POA
POA

(40E45)



CLICK HERE FOR BASIC DIMENSIONS
