Elastomer Temperature capability guide
  Material Continuous Operating Temp ºC
EPDM

Teflon

Viton

Silicone

Buna/Nitrile

Insertion Rubber

Hypalon		 150

250

225

250

125

70

125




Elastomer Chemical compatibility Link


For information on material compatibility, we suggest this link:

 https://www.phelpsgaskets.com/useful-resources/chemical-resistance-chart-elastomers



Including Stainless 316,304 & Polymer Compatibility

This Link Here (pdf doc)








Rigid Plastic Temperature capability guide
  Material Continuous Operating Temp ºC
Polycarbonate

Armour Plate Glass

Pyrex Glass

HDPE

Nylon

Ertalyte TX

 130

250

350

60

80

110





Sheet & Tube Gauge Conversion
  Gauge (#) Thickness in (mm)
24

22

20

18

16

14

12

10

 0.55

0.7

0.9

1.2

1.6

2

2.5

3




Pressure Conversion
  Base Unit Conversion
1 Psi

1 Bar

1 Bar

1 MPa

1 MPa

1 KPa

 6.895 KPa

100 KPa

14.5 Psi

10 Bar

145 Psi

0.145 Psi




Price List Nominal Sizing
  Price List Nomination Imperial Size (in)















  		Price List Nomination Imperial Size (in)















  		Price List Nomination Imperial Size (in)
3mm

6mm

9mm

12mm

18mm

25mm

31mm

38mm

 ⅛

¼

⅜

½

¾

1

1¼

1½

 50mm

63mm

76mm

100mm

125mm

150mm

200mm

250mm

 2

2½

3

4

5

6

8

10

 300mm

350mm

400mm

450mm

500mm

550mm

600mm



12

14

16

18

20

22

24







Stainless Steel Pipe Dimensions

  Sch 10 Sch 40 Sch 80

Size (in)

OD(mm)

WT(mm)

ID(mm)

WT(mm)

ID(mm)

WT(mm)

ID(mm)

⅛

¼

⅜

½

¾

1”

1¼

1½

2

2½

3

3½

4

5

6

8

10

12

10.3

13.7

17.1

21.3

26.7

33.4

42.2

48.3

60.3

73

88.9

101.6

114.3

141.3

168.3

219.1

273.1

323.9

1.24

1.65

1.65

2.11

2.11

2.77

2.77

2.77

2.77

3.05

3.05

3.05

3.05

3.4

3.4

3.76

4.19

4.57

7.82

10.4

13.8

17.1

22.5

27.9

36.7

42.8

54.8

66.9

82.8

95.5

108.2

134.5

161.5

211.6

264.7

314.8

1.73

2.24

2.31

2.77

2.87

3.38

3.56

3.68

3.91

5.16

5.49

5.74

6.02

6.55

7.11

8.18

9.27

9.52

6.84

9.22

12.5

15.8

21.0

26.6

35.1

40.9

52.5

62.7

77.9

90.1

102.3

128.2

154.1

202.7

254.6

304.9

2.41

3.02

3.20

3.73

3.91

4.55

4.85

5.08

5.54

7.01

7.62

8.08

8.56

9.53

11.0

12.7

12.7

12.7

5.48

7.66

10.7

13.8

18.9

24.3

32.5

38.1

49.2

59.0

73.7

85.4

97.2

122.2

146.3

193.7

247.7

298.5

For more Pipe Dimensions Click here for applet



Stainless Steel Tube Dimensions


Unlike Pipe, Stainless Steel Tube inherently has an outside diameter that directly corresponds to the nominal imperial size attributed to the tube eg. 1" (25.4mm) tube has an outside diameter of exactly 1".









Related Standards
  BSM, Flat Faced, IDF, Expandon AS1528 Part 2 (Currently being revised)
Triclover Ferrule Fittings AS1528 Part 1 (Currently being revised)
Din Fittings DIN 11851
SMS Fittings Swedish Manufacturing Standard: SMS 1145
BSP Fittings ISO 4144 (2003)
BSP Thread ISO 7-1
NPT Fittings & Socket Weld Fittings ASME B16.11, MSS-SP-83 (for high press)
NPT Thread ANSI B1.20.1
Butt Weld Pipe Fittings ASTM A403  & ASME B16.9
Tubing AS1528 Part 3 (Currently being revised)
Tubing 8", 10", 12" EN10217-7
Table Flanges AS 2129
ANSI Flanges ASME B16.5
DIN Flanges EN 1092






304 Perforated Mesh Sizes
  Hole Diam (mm) Pitch (mm) Thickness (mm) Open Area (%)

0.5

0.8

1.0

1.6

2

3

4

5

6

8

10

12

15

1

1.5

2

2.54

3.5

4

6

7

8.5

11

13

17

20

0.3

0.5

1

1

1

1

1

1

1

1

1

1.5

1

23

25

23

36

30

50

40

45

45

47

53

45

50




Woven Wire Mesh Info
  Size (Micron) Size (Mesh) Gauge Aperture Open Area (%)
415

310

260

210

190

150

130

100

90

75

63

53

40

38

 40

50

60

70

80

100

120

150

180

200

250

300

350

400

 34

36

37

38

39

42

44

45

47

47

48

48.5

49.5

50

 0.415

0.31

0.26

0.21

0.19

0.15

0.13

0.1

0.09

0.075

0.063

0.053

0.04

0.038

 40

38

35

34

34

36

37

37

42

36

38

35

35

36
25 HOLLANDER WEAVE
10 HOLLANDER WEAVE
5 HOLLANDER WEAVE
